Promtail Tutorial

1️⃣ What is Promtail?¶

Promtail is a log collection agent for Grafana Loki.

👉 Think of it like:

Node Exporter → metrics
Promtail → logs

Promtail:

Reads logs from files / systemd / Docker
Adds labels
Pushes logs to Loki

2️⃣ What Promtail Is NOT¶

❌ Not a log storage system
❌ Not a UI
❌ Not a full log processor like Logstash

👉 Promtail = lightweight log shipper

3️⃣ Where Promtail Fits¶

[ Application / Server Logs ]
        ↓
     Promtail
        ↓
       Loki
        ↓
     Grafana

4️⃣ What Logs Can Promtail Collect?¶

✅ System logs (/var/log/syslog, journalctl)
✅ Application logs (Node, Go, Java, etc.)
✅ Nginx / Apache logs
✅ Docker container logs
✅ Kubernetes pod logs

5️⃣ Installation (Linux – Recommended)¶

Step 1: Download Promtail¶

cd /tmp
wget https://github.com/grafana/loki/releases/latest/download/promtail-linux-amd64.zip

Step 2: Extract¶

unzip promtail-linux-amd64.zip
chmod +x promtail-linux-amd64
sudo mv promtail-linux-amd64 /usr/local/bin/promtail

6️⃣ Promtail Configuration File¶

Create Config Directory¶

sudo mkdir /etc/promtail
sudo nano /etc/promtail/promtail.yml

Basic promtail.yml¶

server:
  http_listen_port: 9080
  grpc_listen_port: 0

positions:
  filename: /var/lib/promtail/positions.yaml

clients:
  - url: http://LOKI_SERVER_IP:3100/loki/api/v1/push

scrape_configs:
  - job_name: system
    static_configs:
      - targets:
          - localhost
        labels:
          job: syslog
          __path__: /var/log/syslog

📌 positions.yaml ensures no duplicate logs

7️⃣ Create Systemd Service¶

sudo nano /etc/systemd/system/promtail.service

[Unit]
Description=Promtail Log Collector
After=network.target

[Service]
User=root
ExecStart=/usr/local/bin/promtail \
  -config.file=/etc/promtail/promtail.yml

[Install]
WantedBy=multi-user.target

Start Promtail¶

sudo systemctl daemon-reload
sudo systemctl enable promtail
sudo systemctl start promtail

Check Status¶

sudo systemctl status promtail

8️⃣ Verify Promtail is Working¶

Check logs:

journalctl -u promtail -f

You should see:

msg="tailing file" path=/var/log/syslog

9️⃣ Loki Setup (Quick Overview)¶

Loki runs on:

http://LOKI_IP:3100

If not installed, basic Docker run:

docker run -d -p 3100:3100 grafana/loki:2.9.0

10️⃣ View Logs in Grafana¶

Step 1: Add Loki Data Source¶

Grafana → Settings → Data Sources → Loki
URL: http://LOKI_IP:3100

Step 2: Explore Logs¶

Explore → Select Loki

Example Query¶

{job="syslog"}

11️⃣ Promtail for Application Logs (Node.js Example)¶

App Log Path¶

/var/www/app/logs/app.log

promtail.yml¶

scrape_configs:
  - job_name: node_app
    static_configs:
      - targets:
          - localhost
        labels:
          job: nodejs
          env: prod
          __path__: /var/www/app/logs/*.log

12️⃣ Parsing Logs (Pipeline Stages)¶

JSON Logs Example¶

pipeline_stages:
  - json:
      expressions:
        level: level
        msg: message

Regex Parsing¶

pipeline_stages:
  - regex:
      expression: '(?P<level>\w+): (?P<msg>.*)'

13️⃣ Promtail with Docker Logs¶

scrape_configs:
  - job_name: docker
    static_configs:
      - targets:
          - localhost
        labels:
          job: docker
          __path__: /var/lib/docker/containers/*/*.log

14️⃣ Promtail with systemd (journalctl)¶

scrape_configs:
  - job_name: journal
    journal:
      path: /var/log/journal
      labels:
        job: systemd

15️⃣ Promtail in Docker¶

docker run -d \
  -v /var/log:/var/log \
  -v /etc/promtail:/etc/promtail \
  grafana/promtail \
  -config.file=/etc/promtail/promtail.yml

16️⃣ Promtail in Kubernetes (Overview)¶

Runs as DaemonSet
Collects logs from:
```
/var/log/pods
```

Standard setup via:

loki-stack Helm chart

17️⃣ Labels – VERY IMPORTANT ⚠️¶

Bad labels ❌

request_id
user_id
timestamp

Good labels ✅

app
env
job
level

👉 High-cardinality labels = Loki crash

18️⃣ Common Issues & Fixes¶

Issue	Fix
No logs	Check `__path__`
Duplicates	Check positions.yaml
Loki down	Promtail retries
High memory	Reduce labels

19️⃣ Promtail vs Alternatives¶

Tool	Type
Promtail	Loki log shipper
Fluent Bit	Logs + metrics
Logstash	Heavy processing
Filebeat	ELK stack

20️⃣ Production Best Practices¶

✔ Use structured logs (JSON)
✔ Avoid high-cardinality labels
✔ Separate prod / staging
✔ Rotate logs
✔ Monitor Promtail itself

🏗️ Full Observability Stack (Best Practice)¶

Metrics → Prometheus + Node Exporter
Logs    → Promtail + Loki
Traces  → Tempo
UI      → Grafana

✅ Final Summary¶

✔ Lightweight & fast
✔ Perfect match for Loki
✔ Easy to configure
✔ Scales well
✔ Ideal for DevOps & Cloud
