🚀 Packer — Full End-to-End Tutorial

(Beginner → Startup → Enterprise)

---

🧠 What Packer Actually Does

HashiCorp Packer builds machine images automatically.

Instead of:

• Manually creating VMs
• Installing software again and again
• Debugging “works on my server”

You:

• Define image once
• Build it consistently
• Reuse it everywhere

---

🧱 Where Packer Fits (Mental Model)

Packer  →  Golden Image  →  Terraform  →  Servers
Bake        Approve          Serve

Packer bakes the server Terraform serves the server

---

1️⃣ Install Packer

Linux

sudo apt update
sudo apt install packer -y

macOS

brew install packer

Verify

packer version

---

2️⃣ Core Packer Concepts (Non-Negotiable)

Term	Meaning
Builder	Where image is built (AWS, Azure, Docker)
Provisioner	What is installed
Source	Image definition
Build	Execution logic
Template	.pkr.hcl file

---

3️⃣ Golden Image Strategy (Enterprise Standard)

What is a Golden Image?

A Golden Image is a secure, hardened, versioned base image approved by platform/security teams.

❌ No SSH fixes ❌ No manual installs ✅ Immutable servers ✅ Fast scaling ✅ Audit-friendly

---

🧱 Golden Image Layers (IMPORTANT)

Layer 1 — OS Base (Rarely changes)

• Ubuntu / RHEL
• OS updates
• CIS hardening
• SSH hardening
• Logging + monitoring agents

Layer 2 — Runtime (Monthly)

• Docker
• Nginx
• Node / Java / Go
• Cloud agents

Layer 3 — App (Optional)

• Legacy apps only
• No secrets
• Not used in Kubernetes-heavy setups

---

🏷️ Naming Convention (Mandatory)

golden-ubuntu-22.04-runtime-v2025.01.15

---

4️⃣ Real Startup-Grade Repo Structure

This is exactly how real startups structure it 👇

packer-images/
├── README.md
├── Makefile
├── .github/
│   └── workflows/
│       └── packer.yml
├── images/
│   ├── ubuntu-base/
│   │   ├── main.pkr.hcl
│   │   ├── variables.pkr.hcl
│   │   └── scripts/
│   │       ├── os-update.sh
│   │       ├── hardening.sh
│   │       └── cleanup.sh
│   └── ubuntu-runtime/
│       ├── main.pkr.hcl
│       ├── variables.pkr.hcl
│       └── scripts/
│           ├── docker.sh
│           ├── nginx.sh
│           └── monitoring.sh
├── modules/
│   └── aws.pkr.hcl
└── scripts/
    └── common.sh

---

5️⃣ Build Golden Base Image (AWS)

Prerequisite

aws configure

---

variables.pkr.hcl

variable "region" {
  default = "ap-south-1"
}

variable "instance_type" {
  default = "t2.micro"
}

---

main.pkr.hcl (Base Image)

packer {
  required_plugins {
    amazon = {
      source  = "github.com/hashicorp/amazon"
      version = "~> 1.3"
    }
  }
}

source "amazon-ebs" "ubuntu-base" {
  region        = var.region
  instance_type = var.instance_type
  ssh_username  = "ubuntu"
  ami_name      = "golden-ubuntu-base-{{timestamp}}"

  source_ami_filter {
    filters = {
      name                = "ubuntu/images/*ubuntu-jammy-22.04-amd64-server-*"
      virtualization-type = "hvm"
    }
    owners      = ["099720109477"]
    most_recent = true
  }
}

---

scripts/os-update.sh

#!/bin/bash
set -e
sudo apt update && sudo apt upgrade -y

scripts/hardening.sh

#!/bin/bash
sudo sed -i 's/PermitRootLogin yes/PermitRootLogin no/' /etc/ssh/sshd_config
sudo systemctl restart ssh

scripts/cleanup.sh

#!/bin/bash
sudo apt autoremove -y
sudo apt clean

---

Build Block

build {
  sources = ["source.amazon-ebs.ubuntu-base"]

  provisioner "shell" {
    scripts = [
      "scripts/os-update.sh",
      "scripts/hardening.sh",
      "scripts/cleanup.sh"
    ]
  }
}

---

Run

packer init .
packer validate .
packer build .

✅ Golden OS Image Ready

---

6️⃣ Runtime Image (Layered on Base)

Change source AMI

source "amazon-ebs" "ubuntu-runtime" {
  ami_name = "golden-ubuntu-runtime-{{timestamp}}"
  source_ami = "ami-BASE_IMAGE_ID"
}

---

scripts/docker.sh

sudo apt install -y docker.io
sudo systemctl enable docker

scripts/nginx.sh

sudo apt install -y nginx
sudo systemctl enable nginx

---

Build Runtime Image

packer build .

✅ Docker + Nginx baked in

---

7️⃣ CI/CD — GitHub Actions

.github/workflows/packer.yml

name: Build Golden Image

on:
  push:
    branches: [main]

jobs:
  packer:
    runs-on: ubuntu-latest
    steps:
      - uses: actions/checkout@v4
      - uses: hashicorp/setup-packer@v3

      - run: packer init images/ubuntu-runtime
      - run: packer validate images/ubuntu-runtime
      - run: packer build images/ubuntu-runtime

---

8️⃣ Terraform Integration (Real Production)

data "aws_ami" "golden" {
  most_recent = true
  owners = ["self"]

  filter {
    name   = "name"
    values = ["golden-ubuntu-runtime-*"]
  }
}

resource "aws_instance" "app" {
  ami           = data.aws_ami.golden.id
  instance_type = "t2.micro"
}

---

9️⃣ Security & Best Practices

✅ No secrets in image ✅ IAM roles only ✅ Disable SSH in prod ✅ Scan images ✅ Immutable deployments

---

🔥 Real Startup Workflow

PR → Packer Build → Scan → Approve → Terraform Apply

No SSH No hotfix No panic

---

🧠 One-Line Summary

Packer creates the server you trust. Terraform runs the server you trust.

---
